Analisis Hubungan Kecepatan Rerata Terhadap Kecepatan Permukaan Untuk Penentuan Kekasaran Dasar Pada Aliran Saluran Terbuka

D.A. Widayanti

doi:10.22487/renstra.v2i2.260

Authors

D.A. Widayanti Departemen Teknik Sipil dan Lingkungan, Universitas Gadjah Mada, Yogyakarta, Indonesia, Indonesia

DOI:

https://doi.org/10.22487/renstra.v2i2.260

Keywords:

the mean flow velocity, the surface flow velocity, the coefficient k value, the ruggedness of Manning

Abstract

The flow velocity of a channel may be used to determine the value of n-Manning, which is the coefficient representing the ruggedness of a hydraulic in a channel. Because of the difficulties in determining the value of n-Manning accurately on the field, this study is aimed to analyze the correlation between the mean flow velocity of a channel (U) and the flow velocity point (u(Vi,dj)) with d = 0.0D; 0.2D; 0.6D in order to determine the precise value of n-Manning of a channel. Vi, the vertical i represents the measurement point of transversal velocity (b/B), dj represents coordinate of the depth value of the flow. In conducting the study, the researcher analyzed the ratio between the mean flow velocity of a channel (U) towards the flow velocity point (u(Vi,dj)) for certain types of channel namely the coefficient k value; it was being analyzed based on several positions of measurement of transversal velocity, b/B. The types of channel used were the natural channel/ rivers (the middle part of Opak River, the upstream of Opak River, and the Kuning River), the Mataram Channel turn, the non-uniform of the Mataram Channel, the laboratory turn channel, and the straight laboratory channel. The result of the analysis of the k value was used to calculate the value of n-Manning. The final result was then compared to the value of n-Manning based on the empirical calculation. Based on the study, the result of the k value of d = 0.0D; 0.1D; 0.2D dan 0.6D for the data on the edge channel (b/B = 0,25) shows the greater range value than the k range value on the middle channel (b/B = 0,50). The k value on the middle channel is stable or relatively equal in all of the determined channels. The n-Manning value based on the k value and the formula of empirical calculation shows the close range value, especially for the data of the rivers and the Mataram Channel. Meanwhile, the data of the laboratory channel shows that the n-Manning value based on the empirical calculation is lower than the nManning value based on the k value.

Downloads

Download data is not yet available.

References

C. Ikhsan, “Analisis Distribusi Kecepatan Aliran Seragam Pada Saluran Terbuka Tampang Segiempat”, Media Teknik Sipil, no. 16, p. 35, 2006.

H. Putro, and J. Hadihardaja, “Variasi Koefisien Kekasaran Manning (n) pada Flume Akrilic pada Variasi Kemiringan Saluran dan Debit Aliran”, Media Komunikasi Teknik Sipil, vol. 19, no. 2, p. 141, 2015.

S. Kimi, “Pengaruh Jenis dan Kemiringan Dasar Saluran Terhadap Nilai Koefisien C Dengan Persamaan Manning Berdasarkan Hasil Uji Laboratorium”, Bearing : Jurnal Penelitian dan Kajian Teknik Sipil, vol. 4, no. 1, p. 1, 2015.

M. Maini, D. Legono, and A.P. Laksitaningtyas, “Evaluasi Estimasi Koefisien Kekasaran Pada Eksperimen Model Fisik”, Jurnal Ilmiah Desain & Konstruksi, vol. 19, no. 1, p. 1 , 2020.

W.L. Nugraha, M.A. Maulana, W. Wardoyo, and S.D. Negara, “Analisis Sensitivitas Kecepatan Rata-rata Kedalaman dan Tinggi Muka Air terhadap Parameter Masukan Setting Model pada Saluran Berbelok 180° dengan Menggunakan Program Bantu Delft3D”, Jurnal Aplikasi Teknik Sipil, vol. 19, no.1, p. 73, 2021.

C. Sujatmiko, “Kajian Nilai Koefisien Hambat Pada Saluran Terbuka”, Jurnal Sains dan Inovasi, vol. 4, no. 1, p. 28, 2008.

M. Maini and D. Legono, “Sensitivitas Hasil Uji Model Fisik Terhadap Perbedaan Penggunaan Angka Kekasaran n-Manning”, FROPIL, vol. 9, no. 1, p. 1, 2021.

O.B. Prismayuda, A. Purnama, and D. Najimuddin, “Analisis Distribusi Kecepatan Pada Saluran Terbuka (Study Kasus : Sungai Pelat, Desa Pelat)”, Jurnal SainTekA, vol. 1, no. 1, p. 1, 2020.

E. Harseno and S. Jonas, “Studi Eksperimental Aliran Berubah Beraturan Pada Saluran Terbuka Bentuk Prismatis”, Majalah Ilmiah UKRIM, vol. 12, no. 2, p. 1, 2007.

G.Y.D. Astuti and Feril Hariati, “Studi Karakteristik Aliran Pada Flume Saluran Terbuka di Laboratorium Teknik Sipil UIKA”, vol. 5, no. 1, p. 16, 2016.

Sumiadi, Aliran Pada Saluran Menikung Dasar Rata dan Dasar Tergerus (Disertasi), Yogyakarta: Departemen Teknik Sipil dan Lingkungan, Fakultas Teknik, Universitas Gadjah Mada, 2014.

M. Maini, Distribusi Konsentrasi Sedimen Suspensi pada Belokan Saluran Terbuka Tampang Trapesium. (Tesis), Yogyakarta: Departemen Teknik Sipil dan Lingkungan, Fakultas Teknik, Universitas Gadjah Mada, 2016.

E.N. Afiato, Distribusi Kecepatan Aliran dan Konsentrasi Sedimen Suspensi pada Aliran Tidak Seragam (Studi Kasus Saluran Mataram Yogyakarta) (Tesis). Yogyakarta: Departemen Teknik Sipil dan Lingkungan, Fakultas Teknik, Universitas Gadjah Mada, 2016.

D.A. Nugroho, Penentuan Kekasaran Dasar Berdasarkan Hasil Pengukuran Distribusi Kecepatan (Tugas Akhir), Yogyakarta: Departemen Teknik Sipil dan Lingkungan, Fakultas Teknik, Universitas Gadjah Mada, 2019.

M. Kiptiah, Distribusi Kecepatan Aliran Sedimen Suspensi pada Sungai Alami (Tesis), Yogyakarta: Departemen Teknik Sipil dan Lingkungan, Fakultas Teknik, Universitas Gadjah Mada, 2016.
